Haibike Yamaha PWX2 - AllMtn CF 12
Please note, the discounted price cannot be used in conjunction with finance. If you wish to purchase this bike via finance please call us on
The 2022 Haibike AllMtn CF 12 is a top-equipped e-Fully for performance-oriented riders who are looking for a versatile bike that can climb uphill and is simply fun to ride downhill. The sporty Yamaha PW-X2 motor ensures a natural riding feel and offers enough range for long rides with its 600 Wh battery. Equipped with 160 mm suspension travel, high-quality Shimano Deore XT gear and brake components and mixed wheel sizes, you have everything you need to master challenging trails without breaking a sweat.
-
-
ENGINE
Yamaha, PW-X2, 250 Wh, 80 Nm, 25 km/h
-
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
-
BATTERY
Yamaha, 600 Wh
-
FRAME FAMILY
Haibike, XDURO AM i600, Carbon
-
FORK
RockShox, ZEB Charger R, Air, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
-
DAMPER
RockShox, Super Deluxe Select, Air, Trunnion Mount
-
CRANK ARM
Raceface, Aeffect, Carbon
-
BRAKE (FRONT)
Shimano, Deore XT M8120
-
BRAKE (REAR)
Shimano, Deore XT M8120
-
TUBE
Presta valve
-
CLAMPING RING
Internal hexagon, 34.9 mm
-
REAR DERAILLEUR
Shimano, Deore XT M8100 Shadow Plus
-
SHIFT LEVER
Shimano, Deore XT M8100, Trigger switch
-
BOTTOM BRACKET
integrated in the motor
-
SPROCKET
Shimano, SLX M7100, 10 - 51 teeth
-
CHAIN
Shimano, SLX M7100
-
CHAINRING
Haibike Components, Aluminium, 38 teeth
-
CHAIN GUIDE
Nylon directmount
-
BRAKE LEVER
Shimano, Deore XT M8100, Aluminium
-
BRAKE DISC (FRONT)
Shimano, RT-MT800LE, 203 mm
-
BRAKE DISC (REAR)
Shimano, RT-EM810, 203 mm
-
TYRE
Maxxis, Assegai MaxxTerra/Exo+/TR, 63-622, 29 x 2.5 inch
-
WHEEL SET
DT Swiss, H1900
-
HANDLEBAR
Haibike Components, TheBar +++ Gravity, 780 mm
-
GRIPS
Haibike, MTB grips
-
STEM
Haibike Components, TheStem 2, A-head, 31.8 mm
-
HEADSET
Acros, BlockLock, Aluminium
-
SADDLE
Prologo, Proxim W400
-
SEAT POST
Dropper-Post Remote, Aluminium, Telescope, 31.6 mm
-
PEDALS
Freeridepedal, Aluminium, with Reflector
-
PERMITTED TOTAL WEIGHT
120.0 kg
-
TYRE (REAR)
Maxxis, Minion DHR II, 71-584, 27.5 x 2.8 inch
-
